Key takeaways
- Helical (sweeping, no central pole) staircases can usually take a curved stairlift.
- True spirals around a central column are harder: tread width and headroom, not the bend, are what rule lifts out.
- Where a spiral cannot take a lift, a through-floor lift is usually the practical alternative.
- Expect custom-rail pricing: roughly £5,000-£10,000+ where feasible.
“Spiral staircase” covers two quite different things, and the difference decides whether a stairlift is realistic. Here is how installers look at yours, and what to expect if you get a yes.
Helical vs true spiral
A helical staircase sweeps in a curve, often around an open well, with reasonably wide treads along the outer edge: from a rail-bending point of view this is just an elegant curved staircase, and modern custom rails follow it happily along the outside of the curve where treads are widest. A true spiral winds tightly around a central column with wedge-shaped treads. The geometry problem is not the bend, today’s rails can be formed to continuous curves, it is that the usable tread width and the headroom envelope shrink toward the column, and the chair plus passenger must clear both for the full rotation.
What the surveyor checks on a spiral
- Outer tread width: the chair needs roughly 700mm+ of usable width along its path: compare minimum stair width.
- Headroom through the rotation, including for the seated passenger’s head and knees.
- A parking spot at top and bottom clear of the door swing and walkway.
- Structure: rails fix to treads, and some ornamental metal spirals need additional fixing solutions.
- Whether the rail can run on the outside of the curve for the entire flight without fouling the well or balustrade.
Costs, and the alternative when it is a no
Feasible spiral and helical installs are bespoke jobs at the top of curved pricing, typically £5,000-£10,000+ in 2026 (curved prices), with manufacture lead times of several weeks (timeline). When the survey says no, usually on tight ornamental spirals, the realistic options are a through-floor lift, relocating the bedroom downstairs, or in listed-building cases a sensitive conversation with the conservation officer before anything else. Get two independent surveys before accepting a no: feasibility judgements on spirals genuinely vary between manufacturers, and surveys are free (get quotes).
Prices are approximate, based on our own research as of June 2026, and vary by supplier, region and staircase. Written in accordance with our editorial policy.
